Master Loader Elite Series Load Frame

The Master Loader Elite series load frame provides multi-purpose loading systems for soil testings. The load frame conducts multiple testing operations such as: CB triaxial, UC, CBR, LBR, Marshall, TSR and SCB asphalt tests. Its heavy-duty design and stepper-motor provides years of reliable service and performs any tests up to a load capacity of 11000 lbf. With its 4-channel data logger and touchscreen controller, the load frame becomes a standalone device of full test control and data logging.

Touchscreen Controller provides:

• 4-channel data acquisition
• Hi-res, 7″, waterproof
• Real-time graphical display of tests
• Control up to 4 different tests at the same time
• 50 readings per second
• 2 USB ports

Specifications:

• Load Capacity – 11000 lbf (50kN)
• Speed range – 0.00001 – 2.00000 in/min
• Data Storage – 1000 tests and up to 3000 readings per test
• Voltage – 110/220V 50/60Hz – 5.0amps

Accessories:

• CBR and LBR Module for Humboldt NEXT Software
